OUR WIDE RANGE PRODUCT


INDUSTRIAL BELT MORE INFO	INDUSTRIAL PULLEY MORE INFO

ROLLER MORE INFO	CONVEYOR MACHINE MORE INFO

ALL APPLICABLE PRODUCT ARE AVAILABLE WITH ALL PITCHES

STANDARED TOOTHED BELTS

T-SERIES
T2.5
Widths: Standard Belt Widths in mm (in between widths available):
4 6 10 12 16 20

pitch/length version \| number of teeth	pitch/length version \| number of teeth
T2.5 / 120 SFX 48 T2.5 / 145 SFX 58 T2.5 / 160 SFX 64 T2.5 / 177.5 SFX 71 T2.5 / 180 SFX 72 T2.5 / 182.5 SFX 73 T2.5 / 200 SFX 80 T2.5 / 225 SFX 90 T2.5 / 230 SFX T2.5 / 245 SFX 98 T2.5 / 250 SFX 100 T2.5 / 265 SFX 106 T2.5 / 285 SFX 114	T2.5 / 290 SFX 116 T2.5 / 305 SFX 122 T2.5 / 317.5 SFX 127 T2.5 / 330 SFX 132 T2.5 / 380 SFX 152 T2.5 / 420 SFX 168 T2.5 / 480 SFX 192 T2.5 / 500 SFX 200 T2.5 / 540 SFX 216 T2.5 / 620 SFX 248 T2.5 / 650 SFX 260 T2.5 / 780 SFX 312 T2.5 / 950 SFX 380 T2.5 / 1300 SFX 520

T5
Widths: Standard Belt Widths in mm (in between widths available):
6 10 12 16 20 25 32 50 75 100

AT5

TRULY ENDLESS - BFX
Widths: Standard Belt Widths in mm (in between widths available):
6 8 10 12 16 20 25 32 50 75 100

pitch/length version | number of teeth

T5 / 150 SFX DL 30
T5 / 260 SFX DL 52
T5 / 300 SFX DL 60
T5 / 410 SFX DL 82
T5 / 460 SFX DL 92
T5 / 515 SFX DL 103
T5 / 525 SFX DL 105
T5 / 590 SFX DL 118
T5 / 620 SFX DL 124
T5 / 625 SFX DL 125
T5 / 750 SFX DL 150
T5 / 815 SFX DL 163
T5 / 860 SFX DL 172
T5 / 940 SFX DL 188
T5 / 1075 BFX DL 215
T5 / 1100 BFX DL 220
T5 / 1215 BFX DL 243
T5 / 1325 BFX DL 265
T5 / 1380 BFX DL 276
T5 / 1400 BFX DL 280
T5 / 1500 BFX DL 300
T5 / 1600 BFX DL 320
T5 / 1700 BFX DL 340
T5 / 1800 BFX DL 360
T5 / 1900 BFX DL 380
T5 / 2000 BFX DL 400
T5 / 2120 BFX DL 424

T5 / 2240 BFX DL 448
T5 / 2360 BFX DL 472
T5 / 2500 BFX DL 500
T5 / 2650 BFX DL 530
T5 / 2800 BFX DL 560
T5 / 3000 BFX DL 600
T5 / 3150 BFX DL 630
T5 / 3350 BFX DL 670
T5 / 3550 BFX DL 710
T5 / 3750 BFX DL 750
T5 / 4000 BFX DL 800
T5 / 4250 BFX DL 850
T5 / 4500 BFX DL 900
T5 / 4750 BFX DL 950
T5 / 5000 BFX DL 1000
T5 / 5300 BFX DL 1060
T5 / 5600 BFX DL 1120
T5 / 6000 BFX DL 1200
T5 / 6300 BFX DL 1260
T5 / 6700 BFX DL 1340
T5 / 7100 BFX DL 1420
T5 / 7500 BFX DL 1500

pitch/length version | number of teeth

AT5 / 2240 BFX DL 448
AT5 / 2360 BFX DL 472
AT5 / 2500 BFX DL 500
AT5 / 2650 BFX DL 530
AT5 / 2800 BFX DL 560
AT5 / 3000 BFX DL 600
AT5 / 3150 BFX DL 630
AT5 / 3350 BFX DL 670
AT5 / 3550 BFX DL 710
AT5 / 3750 BFX DL 750
AT5 / 4000 BFX DL 800
AT5 / 4250 BFX DL 850
AT5 / 1075 BFX DL 215
AT5 / 1100 BFX DL 220
AT5 / 1215 BFX DL 243
AT5 / 1380 BFX DL 276
AT5 / 1400 BFX DL 280
AT5 / 1500 BFX DL 300
AT5 / 1600 BFX DL 320
AT5 / 1700 BFX DL 340
AT5 / 1800 BFX DL 360
AT5 / 1900 BFX DL 380
AT5 / 2000 BFX DL 400

AT5 / 2120 BFX DL 424
AT52240 BFX DL 448
AT5 / 2360 BFX DL 472
AT5 / 2500 BFX DL 500
AT5 / 2650 BFX DL 530
AT5 / 2800 BFX DL 560
AT5 / 3000 BFX DL 600
AT5 / 3150 BFX DL 630
AT5 / 3350 BFX DL 670
AT5 / 3550 BFX DL 710
AT5 / 3750 BFX DL 750
AT5 / 4000 BFX DL 800
AT5 / 4250 BFX DL 850
AT5 / 4500 BFX DL 900
AT5 / 4750 BFX DL 950
AT5 / 5000 BFX DL 1000
AT5 / 5300 BFX DL 1060
AT5 / 5600 BFX DL 1120
AT5 / 6000 BFX DL 1200
AT5 / 6300 BFX DL 1260
AT5 / 6700 BFX DL 1340
AT5 / 7100 BFX DL 1420
AT5 / 7500 BFX DL 1500

T10

TRULY ENDLESS - BFX
Widths: Standard Belt Widths in mm (in between widths available):
12 16 20 25 32 50 75 100

AT10

TRULY ENDLESS - BFX
Widths: Standard Belt Widths in mm (in between widths available):
10 12 16 20 25 32 50 75 100

pitch/length version | number of teeth

T10 / 260 SFX DL 26
T10 / 530 SFX DL 53
T10 / 630 SFX DL 63
T10 / 660 SFX DL 66
T10 / 720 SFX DL 72
T10 / 840 SFX DL 84
T10 / 980 SFX DL 98
T10 / 1080 BFX DL 108
T10 / 1150 BFX DL 115
T10 / 1210 BFX DL 121
T10 / 1240 BFX DL 124
T10 / 1250 BFX DL 125
T10 / 1320 BFX DL 132
T10 / 1350 BFX DL 135
T10 / 1390 BFX DL 139
T10 / 1400 BFX DL 140
T10 / 1420 BFX DL 142
T10 / 1460 BFX DL 146
T10 / 1500 BFX DL 150
T10 / 1560 BFX DL 156
T10 / 1610 BFX DL 161
T10 / 1750 BFX DL 175

T10 / 1780 BFX DL 178
T10 / 1880 BFX DL 188
T10 / 1960 BFX DL 196
T10 / 2250 BFX DL 225
T10 / 2360 BFX DL 236
T10 / 2500 BFX DL 250
T10 / 2650 BFX DL 265
T10 / 2800 BFX DL 280
T10 / 3000 BFX DL 300
T10 / 3100 BFX DL 310
T10 / 3150 BFX DL 315
T10 / 3350 BFX DL 335
T10 / 3750 BFX DL 375
T10 / 4000 BFX DL 400
T10 / 4250 BFX DL 425
T10 / 4500 BFX DL 450
T10 / 4750 BFX DL 475
T10 / 5000 BFX DL 500
T10 / 5300 BFX DL 530
T10 / 5600 BFX DL 560
T10 / 6000 BFX DL 600
T10 / 6300 BFX DL 630
T10 / 6700 BFX DL 670
T10 / 7100 BFX DL 710
T10 / 7500 BFX DL 750
T10 / 8000 BFX DL 800
T10 / 9000 BFX DL 900

pitch/length version | number of teeth

AT10 / 1150 BFX DL 115
AT10 / 1210 BFX DL 121
AT10 / 1240 BFX DL 124
AT10 / 1250 BFX DL 125
AT10 / 1320 BFX DL 132
AT10 / 1400 BFX DL 140
AT10 / 1420 BFX DL 142
AT10 / 1500 BFX DL 150
AT10 / 1530 BFX DL 153
AT10 / 1600 BFX DL 160
AT10 / 1700 BFX DL 170
AT10 / 1800 BFX DL 180
AT10 / 1900 BFX DL 190
AT10 / 2000 BFX DL 200
AT10 / 2120 BFX DL 212
AT10 / 2240 BFX DL 224
AT10 / 2360 BFX DL 236
AT10 / 2500 BFX DL 250
AT10 / 2650 BFX DL 265
AT10 / 2800 BFX DL 280
AT10 / 3000 BFX DL 300
AT10 / 3150 BFX DL 315
AT10 / 3350 BFX DL 335
AT10 / 3550 BFX DL 355
AT10 / 3750 BFX DL 375
AT10 / 4000 BFX DL 400
AT10 / 4250 BFX DL 425
AT10 / 4500 BFX DL 450
AT10 / 4750 BFX DL 475
AT10 / 5000 BFX DL 500
AT10 / 5300 BFX DL 530
AT10 / 5600 BFX DL 560
AT10 / 6000 BFX DL 600
AT10 / 6300 BFX DL 630
AT10 / 6700 BFX DL 670
AT10 / 7100 BFX DL 710
AT10 / 7500 BFX DL 750
AT10 / 8000 BFX DL 800
AT10 / 9000 BFX DL 900

T20
TRULY ENDLESS - BFX
Widths: Standard Belt Widths in mm (in between widths available):
25 32 50 75 100

AT20

TRULY ENDLESS - BFX
Widths: Standard Belt Widths in mm (in between widths available):
25 32 50 75 100

pitch/length version number of teeth	pitch/length version number of teeth
T20 / 1500 BFX DL 75 T20 / 1600 BFX DL 80 T20 / 1700 BFX DL 85 T20 / 1800 BFX DL 90 T20 / 1900 BFX DL 95 T20 / 2000 BFX DL 100 T20 / 2120 BFX DL 106 T20 / 2240 BFX DL 112 T20 / 2360 BFX DL 118 T20 / 2500 BFX DL 125 T20 / 2600 BFX DL 130 T20 / 2660 BFX DL 133 T20 / 2800 BFX DL 140 T20 / 3000 BFX DL 150 T20 / 3160 BFX DL 158 T20 / 3360 BFX DL 168 T20 / 3560 BFX DL 178 T20 / 3620 BFX DL 181	T20 / 3760 BFX DL 188 T20 / 4000 BFX DL 200 T20 / 4260 BFX DL 213 T20 / 4500 BFX DL 225 T20 / 4760 BFX DL 238 T20 / 5000 BFX DL 250 T20 / 5300 BFX DL 265 T20 / 5600 BFX DL 280 T20 / 6000 BFX DL 300 T20 / 6300 BFX DL 315 T20 / 6700 BFX DL 335 T20 / 7100 BFX DL 355 T20 / 7500 BFX DL 375 T20 / 8000 BFX DL 400 T20 / 8500 BFX DL 425 T20 / 9000 BFX DL 450

pitch/length version | number of teeth

AT20 / 1500 BFX DL 75
AT20 / 1600 BFX DL 80
AT20 / 1700 BFX DL 85
AT20 / 1800 BFX DL 90
AT20 / 1900 BFX DL 95
AT20 / 2000 BFX DL 100
AT20 / 2120 BFX DL 106
AT20 / 2240 BFX DL 112
AT20 / 2360 BFX DL 118
AT20 / 2500 BFX DL 125
AT20 / 2600 BFX DL 130
AT20 / 2660 BFX DL 133
AT20 / 2800 BFX DL 140
AT20 / 3000 BFX DL 150
AT20 / 3160 BFX DL 158
AT20 / 3360 BFX DL 168
AT20 / 3560 BFX DL 178
AT20 / 3620 BFX DL 181
AT20 / 3760 BFX DL 188
AT20 / 4000 BFX DL 200
AT20 / 4260 BFX DL 213
AT20 / 4500 BFX DL 225
AT20 / 4760 BFX DL 238
AT20 / 5000 BFX DL
AT20 / 5300 BFX DL 265
AT20 / 5600 BFX DL 280
AT20 / 6000 BFX DL 300
AT20 / 6300 BFX DL 315
AT20 / 6700 BFX DL 335
AT20 / 7100 BFX DL 355
AT20 / 7500 BFX DL 375
AT20 / 8000 BFX DL 400
AT20 / 8500 BFX DL 425
AT20 / 9000 BFX DL 450
